3-12mm 2 Flutes 90 Degrees Chamfer End Mill CNC Router Bit TiSiN Coated HRC55
1. 100% brand new and high quality.
2. Chatter resistant design for superior surface finishes and long tool life
3. Unique one-piece design, the debris can be chamfered in the process of generating a more convenient fall, the situation will not be delayed because of clogging tool ergonomics
4. Cutting reasonable matched with high strength of Chamfer
5. More convenient way of protecting the tool can be polished without unloading
6. It can process all types of soft or black metal, improved edge of the tool life twice as long
1. 100% brand new and high quality.
2. Chatter resistant design for superior surface finishes and long tool life
3. Unique one-piece design, the debris can be chamfered in the process of generating a more convenient fall, the situation will not be delayed because of clogging tool ergonomics
4. Cutting reasonable matched with high strength of Chamfer
5. More convenient way of protecting the tool can be polished without unloading
6. It can process all types of soft or black metal, improved edge of the tool life twice as long
Products Function
Material | Tungsten Cobalt Alloy, Tungsten Carbide | Machine Type | Milling Machine |
Controlling Mode | CNC Tooling System | Precision | 0.005-0.01mm |
Shank Diameter | 4-40mm | Coating | AlTiN, TiAlN, TiAISI,TiSiN, TiN, DLC,Nano, Diamond |
Flute Diameter | 0.3-40mm | HRC | HRC55 HRC60 |
Overall Length | 38-330mm | Suitable For | cast iron, carbon steel, mould steel, stainless steel, titanium alloy, tool steel, and heat-treated steel |
Products Features
1. Special Cutting Edge: Special cutting edge can increase the cutting ability. The lifetime of tools and machines will be longer
2. Smooth And Wide Flute: Smooth and wide flute will remove the cuttings more easily
3. Heat-resistant Coating: With highly heat-resistant HELICA coating, can be used for high-speed processing
4. Bronze Coating: Under bronze coating, any abrasion is easy to be recognized
5. High Quality Raw Material: The raw material is used of high toughness, grain-sized carbon tungsten
6. Polished Surface Treatment: With high polished surface treatment, reduce the friction coefficient could be reduced, the lathe efficiency could be improved, more production time could be saved
Standard type
Model No. | Flute Diameter(mm) | Angle(°) | Shank Diameter(mm) | Overall length(mm) | Number of Teeth |
D1*90°*D4*50 | 1 | 90° | 4 | 50 | 2 |
D1.5*90°*D4*50 | 1.5 | 90° | 4 | 50 | 2 |
D2*90°*D4*50 | 2 | 90° | 4 | 50 | 2 |
D2.5*90°*D4*50 | 2.5 | 90° | 4 | 50 | 2 |
D3*60°*D4*50 | 3 | 60° | 4 | 50 | 3 |
D3*90°*D4*50 | 3 | 90° | 4 | 50 | 3 |
D3*120°*D4*50 | 3 | 120° | 4 | 50 | 3 |
D3.5*90°*D4*50 | 3.5 | 90° | 4 | 50 | 3 |
D4*60°*D4*50 | 4 | 60° | 4 | 50 | 3 |
D4*90°*D4*50 | 4 | 90° | 4 | 50 | 3 |
D4*120°*D4*50 | 4 | 120° | 4 | 50 | 3 |
D5*60°*D5*50 | 5 | 60° | 5 | 50 | 3 |
D5*90°*D5*50 | 5 | 90° | 5 | 50 | 3 |
D5*120°*D5*50 | 5 | 120° | 5 | 50 | 3 |
D6*60°*D6*50 | 6 | 60° | 6 | 50 | 3 |
D6*90°*D6*50 | 6 | 90° | 6 | 50 | 3 |
D6*120°*D6*50 | 6 | 120° | 6 | 50 | 3 |
D8*60°*D8*60 | 8 | 60° | 8 | 60 | 3 |
D8*90°*D8*60 | 8 | 90° | 8 | 60 | 3 |
D8*120°*D8*60 | 8 | 120° | 8 | 60 | 3 |
D10*60°*D10*75 | 10 | 60° | 10 | 75 | 3 |
D10*90°*D10*75 | 10 | 90° | 10 | 75 | 3 |
D10*120°*D10*75 | 10 | 120° | 10 | 75 | 3 |
D12*60°*D12*75 | 12 | 60° | 12 | 75 | 3 |
D12*90°*D12*75 | 12 | 90° | 12 | 75 | 3 |
D12*120°*D12*75 | 12 | 120° | 12 | 75 | 3 |
Extra Length Type
Model No. | Flute Diameter(mm) | Angle(°) | Shank Diameter(mm) | Overall length(mm) | Number of Teeth |
D8*90°*D8*75 | 8 | 90° | 8 | 75 | 3 |
D10*90°*D10*75 | 10 | 90° | 10 | 75 | 3 |
D12*90°*D12*75 | 12 | 90° | 12 | 75 | 3 |
Show Details
Clients Benefits:
1. More revenue: due to our big stocks, tools cost can be controlled. With our competitive price, we can help you to make even more revenue but with lower cost.
2. No quality complain: By control quality from raw material to production process and 100% examed before shipment, so we can help you to keep away from any clients complain for quality issue.
3. One stop shop service: we have variety of cnc milling tools, cnc router bits and cnc drilling tools. You do not need to buy everywhere and pay shipping cost everywhere.
4. Increase clients conversion rate: with our technical and market experience, we can help you to generate more customer with even higher conversion rate.
5. Fast feedback: we offer 24 hours online service, any questions from you or your clients will be replied immediately, your clients will be happy, then you will be happy.
6. Cutomized tools: Customized tools can be provided acccording to your drawing and your work piece.
